Home Home solar power system 24V 1000W Home Complete Off Grid Solar Power System

24V 1000W Home Complete Off Grid Solar Power System

This 1000w off grid solar power system is an ideal ready-to-use kit for off-grid applications, which provides reliable and constant power for household appliances or industrial equipment in areas where there is no or no stable mains power.

  • Payment:

    T/T
  • Product Origin:

    China
  • Power:

    1000W
  • Type:

    Off-grid
  • Certificate:

    CE, RoSH
  • Product Detail

24V 1000W Home Complete Off Grid Solar Power System


This product is a multifunctional solar home energy system with DC output, which can be used for the load of household appliances, such as refrigerators, washing machines, rice cookers, computers, TVs, fans, lights, etc. This is the best choice for solar home power systems.

1000W Off Grid Solar Power System Specifications:
1000W MPPT Solar Charge Controller:

Multifunctional protection

Pure sine wave output, full power

100% uninterrupted power

Default battery system voltage (VDC) 12VDC/24VDC/48VDC
Inverter Output Rated power 1000W
Surge rating (20ms) 3000W
Capable of starting electric Motor 0.5HP
Wave form Pure sine wave/ Same as input (AC mode)
Nominal output voltage RMS 110/120VAC 220/230/240VAC(±10RMS)
Output frequency 50Hz60Hz±0.3Hz
Inverter efficiency(Peak) >85%
Line mode efficiency >95%
Typical transfer time 8ms(Max)
Solar Charge Controller Max solar charging current 30A,40A,50A,60A,80A
Voltage 12V,24V,48V,96V
Max PV input power 12V-30A:360W,12V-50A:600W,12V-60A:720W,12V-80A:960W,12V-100A:1200W,12V-120A:1440W
24V-30A:720W,24V-50A:1200W,24V-60A:1440W,24V-80A:1920W,24V-100A:2400W,24V-120A:2880W
48V-30A:1440W,48V-50A:2400W,48V-60A:2880W,48V-80A3840W,48V-100A:4800W,48V-120A:5760W
96V-80A:7680W,96V-100A:9600W,96V-120A:11520W
PV array MPPT voltage range 12V:18V-100V,24V:36V-130V,48V:72V-160V,96V:144V-280V
Peak conversion efficiency >99%
Other Mounting Wall mount
Display LCD+LED
Cooling fan Intelligent fan cooling system
Audible noise <60dB
Coommunications RS-232,SNMP,WI-FI,Dry Contact(Optional)
Operation temperature range -10℃~50℃
Storage temperature -10℃~60℃
Protection Over load protection Rated power over 110%,shut down automatically
Temperature protection Built-in temperature sensor real-time induction, ,≥85 alarm, ,≥85 shut down the whole machine
Short circuit protection Automatic Shutdown
Battery Low battery protection 10VDC±0.3V (12VDC),20VDC±0.3V (24VDC),40 VDC±0.3V (48VDC),80 VDC±0.3V (96VDC)
Low battery cutoff 10.5VDC±0.3V (12VDC),21VDC±0.3V (24VDC),42 VDC±0.3V (48VDC),84VDC±0.3V (96VDC)
High Battery alarm 15VDC±0.3V (12VDC),30VDC±0.3V (24VDC),60 VDC±0.3V (48VDC),120 VDC±0.3V (96VDC)
High Battery protection 16.5VDC±0.3V (12VDC),33VDC±0.3V (24VDC),66VDC±0.3V (48VDC),132VDC±0.3V (96VDC)



Solar panels:


Polycrystalline Solar panels *2

Maximum output power (Pm)

330W

Best working voltage (Vmp)

37.8V

Best working current (Imp)

8.74A

Open circuit voltage (Voc)

46.9V

Short circuit current (Isc)

9.14A

Maximum rated fuse current

20A

Maximum system voltage

1000VDC

Size

1956*992*40mm

Weight

About 22.5KG

Conversion efficiency

18%

Power deviation

3%

Cell

Polysilicon

Service life

More than 25 years


Batteries:


Maintenance-free battery *2

Battery Type

Valve-controlled maintenance-free gel battery

Voltage

12V

Capacity

150AH

Size

483*170*240mm

Weight

About 42KG


Accessories:


Solar Panel Parallel Head

1 pair

Anti-reverse diode

2 pcs

Bracket

Custom

Battery series line

Custom

Solar panel connection line

Custom

Host connection line

Custom



Can bring electrical appliances within 3000W
  • Refrigerator (200W): Use alone for about 18 hours
  • Rice cooker (500W): Use alone for about 7 hours
  • Microwave oven (700W): Use alone for about 5 hours
  • TV (100W): Use alone for about 36 hours
  • Water pump (400W): Use alone for about 9 hours
