POLY Solar Panels Suitable For: Home solar systems, Industrial & commercial roof, Utility scale.
Payment:
TTProduct Origin:
ChinaPower:
300-335WWarranty:
10 years
Electric Performance Typical Performance Characterics
|
Short Circuit Current Temperature Coefficiant %/°C |
0.06 |
|
Open Circuit Voltage Temperature Coefficient %/°C |
-0.34 |
|
Maximum Power Temperature Coefficient %/°C |
-0.47 |
|
Performance Warranty : 90%output, 12 years |
|
|
80%output, 25 years |
Product Specification
|
Type Of Module |
LBT-300W |
LBT-305W |
LBT-310W |
LBT-315W |
LBT-320W |
LBT-325W |
LBT-330W |
|
Maximum Power (W) |
300 |
305 |
310 |
315 |
320 |
325 |
330 |
|
Tolerance (%) |
±3% |
±3% |
±3% |
±3% |
±3% |
±3% |
±3% |
|
Open Circuit Voltage (V) |
43.7 |
43.9 |
44.2 |
44.4 |
44.6 |
45.0 |
45.1 |
|
Short Circuit Current (A) |
8.73 |
8.82 |
8.92 |
9.01 |
9.11 |
8.96 |
9.29 |
|
Maximum Power Voltage (V) |
36.1 |
36.3 |
36.5 |
36.7 |
36.9 |
37.2 |
37.3 |
|
Maximum Power Current (A) |
8.31 |
8.40 |
8.49 |
8.58 |
8.67 |
8.74 |
8.85 |
|
Module Efficiency (%) |
15.5 |
15.7 |
16.0 |
16.2 |
16.5 |
16.7 |
17.0 |
|
Solar Cell Efficiency (%) |
17.48 |
17.77 |
18.07 |
18.36 |
18.65 |
18.94 |
19.23 |
|
Series Fuse Rating (A) |
15 |
15 |
15 |
15 |
15 |
15 |
15 |
|
Terminal Box |
IP65 |
||||||
|
Maximum system voltage (V) |
DC1000 |
||||||
|
Operating Temperature(°C) |
-40 °C -85°C |
||||||
|
Dimension |
1956*992*35MM OR 1956*992*40MM |
||||||
|
Weight |
22KG/PCS |
||||||
|
Packing |
2 pcs in one carton or 26pcs/ pallet |
||||||
Quality Assurance
• Electrical Insulation test
• Outdoor exposure test
• Hot-spot endurance test
• UV-exposure
• Thermal cycling test
• Humidity freeze test
• Damp heat Test
• Robustness of terminations test
• Wet leakage current test
• Mechanical load test
• Hail impact test
• Bypass diode thermal test
Solar Panels Feature
• Bypass diode minimizes the power drop by shade.Enter details about your solar energy needs and we will get back to you as soon as we can. ( Whatsapp: +86 18559227773)
We provide a series of monocrystalline and polycrystalline photovoltaic modules. Our panels comply with IEC standards and are suitable for a wide range of applications.
Solar cells using monocrystalline technology often appear on high-end solar panels. This is because they can provide more power output for the space they use. Higher efficiency makes single panels more suitable for commercial installations. This may include large office buildings, factories and solar farms.
Mini portable solar systems, suitable for indoor lighting, outdoor lighting, insufficient electricity, no electricity, home lighting and mobile phone charging.
With a 3kw solar pv panel system, any excess energy generated from the solar panels during the day will be used to charge the battery so that the energy can be used when needed.
This 1000w off grid solar power system is an ideal ready-to-use kit for off-grid applications, which provides reliable and constant power for household appliances or industrial equipment in areas where there is no or no stable mains power.
This is an intelligent power frequency solar inverter, which solves the problem of use in home, outdoor and other places.
5W solar energy system intelligent controller, dual USB design, meets various power needs for mobile phone lighting, emergency lighting, night market stalls, and deep mountains and seas.
The solar power portable systems includes a waterproof, high-efficiency 20W solar panel, which is ideal for permanent use outdoors and can power various devices for many applications (such as LED lights, fans, mobile phones, etc.).
If you are interested in our products and want to know more details,please leave a message here,we will reply you as soon as we can.
CXMSOLAR is an international, diversified and fully developed company dedicated to providing home solar power systems. Established in 2004, specializing in the development, manufacturing and sales of solar cells and modules, as well as the design of solar power generation systems.
